Description
- Clipping system with a high degree of robustness and reliability for manual tubular mesh bagging.
- Enables pack finishing with Bolduc strap between 12 and 30mm width.
- Available accessories: Wineglass tags dispenser or Bolduc strap holder, and different sets of tubes for different mesh width loads.
Main Features
- Available for single phase or Three phase electricity connectivity.
- Standard tube accessories of 150mm.
- Optional tube accessories ranging from 90mm to 200mm diameter.
- Wineglass tag dispenser 75x40mm.
- Bolduc tape holder optional.
- Second accessories set, in case a second mesh preload is wanted simultaneously.
Technical Specifications
| Model | CHEQ-120 |
| Machine Weight | 90 Kg |
| Installed Electrical Power | 0.5 kW |
| Power Supply Voltage/MCB | 415V / 50Hz, 32 A |
| Acoustic Pressure | 70 dB |
| Weight of Individual Packs | 250g – 3000g |
| Working Temprature | From -10° C to +50° C |
| Production Speeds | Up to 30 packs/min depending on product type and weight of individual packages |
| Layout Space in Milimeters | 850 x 1100 x 1500 mm |
